Sense™

Take your world from physical to digital with 3D Scanning
Sense™

Capture your world in 3D and discover the power of physical photography with the Sense 3D scanner. Savor every dimension of your favorite memories: Graduation day. Wedding day. Bringing home baby. Holidays. Trips around the world. All with your Sense, all in 3D.

Scan small, scan large, scan it all

Sense 3D scanner scans small and large objects, people and scenes. The Sense 3D scanner has the most diverse scan range in its class with auto-optimized settings for small and large objects like a book or a motorcycle, heads to full bodies and scenes as large as 10 feet tall and wide.

Mash-up your world

Merge your scans in Cubify Sculpt™, the ultimate consumer software for editing STLs, mash-ups and organic modeling. Full integration between the Sense 3D scanner and Cubify Sculpt gives you the creative freedom to import your scans and combine them with other favorite designs.

Zero in on what matters

Automatic object recognition extracts precise targets from the busiest of backgrounds, scanning only the object you want.

Edit confidently

Sense 3D scanner software is intuitive, fast, accurate and easy to use. Scans process in seconds and can be cropped, enhanced and solidified for printables in just minutes. No design experience is necessary.

For your life on the go

Hand-held mobility gives you the freedom to scan spontaneously, everywhere you go.


Physical to digital and back again

Sense 3D scanner is fully integrated with Cubify.com and your Cube 3D printer. Scans can be uploaded directly for cloud printing with a variety of materials on Cubify.com, or sent directly to your 3D printer.

System Requirements

PC

  • Intel® Core i5™ or equivalent processor
  • RAM: 2 GB minimum
  • 1280 x 1024 minimum screen resolution
  • Colour: 32-bit
  • 4 GB available hard disk space

MAC

  • Intel® Core i5™ or equivalent processor
  • RAM: 4 GB minimum
  • Mac OS X 10.8 or later
  • 64-bit O/S

Technical Specifications

Dimensions 17.8 cm × 12.9 cm × 3.3 cm
Scan volume Min: 0.2 × 0.2 × 0.2 m - Max: 3 × 3 × 3 m
Depth image size 240 (w) × 320 (h) px
Field of view Horizontal: 45°, Vertical: 57.5°, Diagonal: 69°
Operating range Min. 0.35 m - Max: 3 m
Operating temperature 10-40° C
Depth resolution @ 0.5 m 1 mm
Warranty 1 year
Spatial x/y resolution @ 0.5 m 0.9 mm
Max power consumption 2.25 watts
Data interface USB 2.0 / USB 3.0
Data format 16 bit
Colour Image Size 240 (w) × 320(h) px
